The Euchips EUP45T-1HMC-0 is a 40W constant current LED driver built for TRIAC and ELV phase-cut dimming. It suits residential and commercial lighting where smooth, flicker-free control matters, and its output current can be set on site rather than fixed at the factory.

Key features

• Output current: adjustable from 300mA to 1400mA via DIP switch, with a current tolerance of ±5%.
• Output voltage: 3V to 65V DC.
• Input supply: 200 to 240V AC, 47 to 63Hz.
• Dimming: TRIAC and ELV, leading and trailing edge, 0 to 100% range, flicker-free.
• Power factor: ≥0.93, with active PFC.
• Efficiency: up to 80%.

Protection and build

• Short circuit, overload and over temperature protection, each recovering automatically once the fault clears.
• Class II construction in a fully enclosed housing.
• IP20 rated, for indoor use, with an operating range of -40°C to +60°C.
• Dimensions 171.5 x 54 x 20mm, weight approximately 225g.

Applications

Suits LED downlights, spotlights, panel and ceiling lights, and decorative or architectural fittings in residential and commercial installations.

Installation note

This driver is for indoor use only. Fit it in a well-ventilated position and have installation carried out by a qualified electrician.
