All AC Dimmable Power Supplies
White rectangular LED driver with ribbed ventilation panels, certification marks, and product labeling visible on top surface

Boke Constant Current LED Driver 18W 450mA Non-Dimmable | BK-PDL016-450A

£17.80
Skip to product information
White rectangular LED driver with ribbed ventilation panels, certification marks, and product labeling visible on top surface

Boke Constant Current LED Driver 18W 450mA Non-Dimmable | BK-PDL016-450A

Vendor
Boke
SKU
002701
Availability
Sold out
Weight
0.1 kg

£17.80inc VAT £14.83exc VAT

Sorry, this one is sold out

Tell us you want it and we will find out when it is back, or point you at the closest thing we have in stock.

Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs

Secure checkout
Payment methods
  • American Express
  • Apple Pay
  • Bancontact
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Product Description

The Boke BK-PDL016-450A supplies a steady 450mA constant current to LED loads of up to 18W. It runs from a 200-240VAC mains input at 50/60Hz, with a maximum output voltage of 50Vdc. This model is not dimmable.

Boke constant current LED driver features

  • Output: 450mA, 18W Max, with 5% constant current accuracy
  • Input: 200-240VAC, 0.15A, 50/60Hz, input voltage range 180-264VAC
  • Power factor: PF>0.90 @ 230VAC/>70% load
  • Efficiency: 88%
  • Protection: hiccup mode, recovering automatically after the environment temperature declines
  • Approvals: CE-SUD ENEC SAA RCM, safety standard EN61347-1/2-13

Where it fits

This driver is intended for low-power LED fittings that need a constant current supply. Typical loads include downlights, spotlights, round panel lights and LED panels, along with T8 and T5 LED tubes and general LED arrays. It is a straightforward choice where the light runs at a fixed output.

Installation notes

The driver is rated IP20. Mount it inside a fitting or an enclosure, not in an exposed position. The casing measures L111*W42*H25.5mm and weighs 74.4g, small enough to sit in the void above many downlights and panels. Pair it with an LED load that runs at 450mA and stays within the 50Vdc maximum output voltage.

Remember that it is non-dimmable. If the circuit needs dimming, this is the wrong driver.

Technical Specifications 23 rows Show
BrandBoke
ModelBK-PDL016-450A
TypeConstant current LED driver
Input200-240VAC - 0.15A
Frequency50/60Hz
Input voltage range180-264VAC
Power factorPF>0.90 @ 230VAC/>70% load
Total harmonic distortionTHD<20% @ 230VAC/>70% load
Efficiency88%
Inrush currentCold start <30A @ 230Vac.
Max output voltage50Vdc
Output current450mA
Constant current accuracy5%
Rated power18W Max
DimmingNot dimmable (N/A)
ProtectionHiccup,recovers automatically after environment temperature declines
Operating temperature-20-45
IP ratingIP20
DimensionsL111*W42*H25.5mm
Weight74.4g
MTBF500000H,MIL-HDBK-217F(25)
Safety standardsEN61347-1/2-13
CertificatesCE-SUD ENEC SAA RCM

Manufacturer datasheet. Figures as published by the manufacturer.
