50W LED Driver Constant Current 1200mA 28-42V Linear | Boke BK-CWL050-1200A
- Vendor
- Boke
- SKU
- 002419
- Availability
- Pre-order
- Weight
- 0.15 kg
Not in stock right now. We will confirm the lead time before dispatch.
£14.69inc VAT £12.24exc VAT
Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
The Boke BK-CWL050-1200A is a slim linear 50W LED driver with a fixed constant current output of 1200mA across DC28-42V. It powers LED panels, downlights, tube lights, tri-proof fittings and other linear lights. The slim metal housing is built to sit inside the luminaire itself.
Why choose this 50W LED driver
- Output: DC28-42V at 1200mA, with a maximum output power of 50.4W and a maximum output voltage of 50VDC.
- Mains input: 200-240V, 0.4A max, 50/60Hz, with a power factor of 0.95 or more.
- Flicker-free: meets the ErP requirements, and power-on time is under 0.5s.
- Protection: short-circuit and over temperature protection.
- Emergency lighting: supports both central and self-contained emergency systems.
- Guarantee: 5-year guarantee and a nominal life-time of up to 100,000 h.
Installation and use
This is an IP20 driver for indoor use only. It follows a SELV and Class I design, so it can be built into metal or plastic light fittings. Wiring is simple. Three input terminals take live, neutral and earth from the 200-240VAC mains supply.
Because the current is fixed at 1200mA, check that your LED board or module is rated for that current and runs within the 28-42V window before fitting.
Size and approvals
The housing measures L285 x W30 x H21 mm, narrow enough for linear fittings and batten bodies. The driver is certified CE, UKCA, ENEC-TUV, RCM, CCC and EL, which matters to installers working to recognised standards on commercial jobs.
Technical Specifications 36 rows Show
| Brand | Boke |
| Model | BK-CWL050-1200A |
| Series | CWL Series |
| Regulation method | Constant Current |
| Output current | 1200mA |
| Output current adjustment | Fixed output |
| Output voltage | DC28-42V |
| Max. output voltage | 50VDC |
| Max. output power | 50.4W MAX. |
| Input | 200-240V ~ 0.4A MAX 50/60Hz |
| Rated input voltage | 200-240VAC 200-240VDC |
| Input voltage shock | <380 V AC |
| Efficiency (typ.) | 89% |
| In-rush current | 18.3A peak ,300us duration(50 % Ipeak) |
| Power on time | <0.5s |
| Flicker (IEEE 1789) | Flickering percent=0.286%(100Hz), Flicker index=0.001(100Hz), Pst LM = 0.011, SVM = 0.006 |
| Protection | SCP/OTP |
| Withstand voltage | I/P-O/P:3750VAC,I/P-FG:1750VAC,O/P-FG:500VAC |
| Mains surge capability | L-N:2KV,L-FG/N-FG:2KV |
| Leakage current | 0.43mA |
| Emergency support | Central and self-contained emergency systems supported |
| EL compatibility | IEC 61347-2- 13 Annex J , compatible with EN 60598-2-22 and EN 50172 |
| Design | SELV and Class I design, suitable for use built-in of the light |
| IP grade | IP20 |
| Operating temperature | Ta=-20-60 |
| Case temperature | Tc=90 |
| Operating humidity | 5-85% RH, not condensed |
| MTBF | 500,000H,MIL-HDBK-217F(25) |
| Life-time | Nominal life-time up to 100,000 h |
| Acoustic noise | <25dB(30cm, Normal operation) |
| Dimensions | L285*W30*H21 mm |
| Weight | 204g |
| Certifications | CE, UKCA, ENEC-TUV, RCM, CCC, EL |
| Safety standards | EN61347-1, EN61347-2-13, EN62384 |
| EMC standards | EN55015, EN61000-3-2 , EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 |
| Guarantee | 5-year guarantee |
Manufacturer datasheet. Figures as published by the manufacturer.
