LED Gear Tray Replacement 16W Microwave Sensor Emergency 2700K | Ledison

£46.15
Skip to product information
Internal view of circular LED gear tray showing yellow LED chips arranged in ring pattern, driver electronics, and terminal c

LED Gear Tray Replacement 16W Microwave Sensor Emergency 2700K | Ledison

Vendor
Ledison
SKU
101026
Availability
Sold out
Weight
0.313 kg

£46.15inc VAT £38.46exc VAT

Sorry, this one is sold out

Tell us you want it and we will find out when it is back, or point you at the closest thing we have in stock.

Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs

Secure checkout
Payment methods
  • American Express
  • Apple Pay
  • Bancontact
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Product Description

This Ledison 16W LED gear tray replacement puts a microwave sensor and an emergency battery into a single unit. It takes the place of a 28W or 36W 2D fluorescent lamp inside a round ceiling or wall light, so the existing fitting can stay where it is. Light output is 1400lumen in warm white 2700K.

LED gear tray replacement features

  • Power and output: 16 watts, warm white 2700K, 1400lumen
  • Emergency backup: emergency driver with NI-CD battery at 3.6V, 3 hours
  • Microwave sensor: full brightness when movement is detected, then down to 10% or 0% (user adjustable)
  • Corridor function: the 10% level can be turned off, after which the light switches off once the hold time ends
  • LED chips: SMD2835
  • Dimming: not dimmable

How it operates

In normal use it acts like any other light, controlled from a wall switch or by the built-in sensor. Lose the mains and it changes role. The tray then runs from its battery as a maintained emergency fitting for 3 hours.

Installation

The tray is 262mm in diameter and is built around a fully insulated junction box. Supply connections go to a 4-way power block with the following terminals:

  • Switched live
  • Unswitched live (emergency)
  • Neutral
  • Earth

The switched live handles everyday on and off control, while the unswitched live is the emergency feed.

Where it fits

It suits round ceiling and wall lights that currently run a 28W or 36W 2D lamp. Swapping in this tray adds motion control and emergency cover in one job, without replacing the whole fitting. For installers working through a building with older 2D lights, that keeps the work to the gear tray alone.

Technical Specifications 18 rows Show
Fitting2D/4pin
Wattage (rated)16 Watt
Luminous flux1400lumen (warm white 2700K)
Colour rendering index>80
Voltage100-265Volt
Line frequency50/60Hz
Beam angle120deg.
Average lifetime50,000 hours
Current250mA
Colour temperature2700K
Power factor0.95
Dimensions262mm diameter
BatteryNI-CD battery at 3.6V
Emergency duration3 hours
DimmableNO
Operating temperature-20 OC to 45 OC
CertificationTUV, ROHS Compliant, CE, UL
Warranty5 years - LED, 1 year - emergency

Manufacturer datasheet. Figures as published by the manufacturer.
