This Boke PQL driver is a replacement constant current power supply for LED lights up to 20 watts, rated to 22 watts including driver tolerance. It suits LED panels, downlights and spotlights that use an external driver, and is not intended for fixtures with a built-in driver. The output is flicker-free and Boke backs it with a 5 year warranty.

LED driver power supply features

• Flicker-free output meeting the ErP standard
• Screw-free design for easy wiring
• Pushable strain relief design for simple crimp installation
• Compact housing
• Dual-stage circuit design for stable operation
• High PF, high efficiency, low THD, SELV and Class II design suitable for use outside the light fitting
• Certified to CE, UKCA, ENEC-TUV, RCM, CCC and EL standards

Technical specifications

• Input voltage: 200-240VAC
• Maximum input power: 22.8Watt
• Output voltage: 28-50VDC
• Output current: 0.4-0.6A
• Power factor: 0.95
• Efficiency: 86%
• THD: 15%

Applications

Use this driver to replace a failed constant current power supply on LED panels, downlights and spotlights that take an external driver. It is not a fit for lights with an integrated driver, so check the original fitting before ordering.
