Boke Dimmable Constant Current LED Driver 42W 1100mA DALI-2 | BK-DUL042-B1100ADF
- Vendor
- Boke
- SKU
- 002597
- Availability
- In stock
- Weight
- 0.15 kg
£27.25inc VAT £22.71exc VAT
Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
This Boke constant current LED driver gives you three dimming methods in one unit: DALI-2, a push switch (Push-Dim with corridor function) and 1-10V or 10V PWM. It delivers up to 42W, and a DIP switch selects one of 16 current levels so the output matches your LED light, up to 1100mA.
Boke dimmable constant current LED driver features
- Control interfaces: DALI-2 (DALI-2 DT6), PUSH and DIM (1-10V / 10V PWM)
- Output: 42W max, 0.45-1.1A current range, 6-42VDC output voltage
- Current setting: 16 levels via DIP switch
- Dimming: 1 ~100% range with soft, flicker-free output at any brightness, plus 2% output current accuracy
- Standby power: input<0.5W
- Safety: SELV and Class II, IP20, for indoor use
Installation
Wiring goes into screw-free terminals. Pressing-type strain relief takes thicker cables, and the input and output sides each have their own. Protection covers hot-plugging, short circuits and no-load conditions.
The driver also supports both central and self-contained emergency applications, which makes it suitable for circuits that form part of an emergency lighting scheme.
Where it fits
Use it as a separate, independent driver for downlights, spotlights and panel lights in offices, commercial premises and other indoor spaces. It is not suitable for lights that already have a built-in driver. Check the current your LED light needs before setting the DIP switch.
Lifetime and guarantee
Boke quotes a nominal lifetime of up to 100,000h. Cover is a 5-year guarantee.
Technical Specifications 32 rows Show
| Brand | Boke |
| Model | BK-DUL042- B1100ADF |
| Type | Constant current LED driver |
| Max current | 1100mA |
| Output voltage | 6-42VDC |
| Current setting | DIP S.W(16 levels) |
| Dimming | DALl-2+PUSH+l-10V/10V PWM |
| Dimming range | 1 ~100% |
| Output current accuracy | 2% |
| Standby power | input<0.5W |
| Safety | SELV and Class II design |
| IP rating | IP20 |
| Lifetime | up to 100,000h |
| Rated input voltage | 200-240VAC 200-240VDC |
| Input voltage range | 180-264VAC 180-264VDC |
| Input current | <0.25A (Rated input voltage) |
| Input power at full load | 47.2W |
| Power factor | PF: 0.97 |
| THD | 8.5% |
| Efficiency | 89% |
| No load output voltage | 50VDC |
| Emergency | Central emergency system and self-contained emergency supported |
| Switching cycles | > 100,000 switching cycles |
| Operating temperature | Ta=-20-45 |
| Case temperature | Tc=90 |
| MTBF | 500,000H,MIL-HDBK-217F(25) |
| Acoustic noise | <25dB(30cm,Normaloperation) |
| Dimensions | L103*W68.5*H31mm |
| Certifications | ENEC-TUV, CE, RCM, CCC, DALl-2 |
| Warranty | 5-year guarantee |
| Power | 42W Max |
| Current range | 0.45-1.1A |
Manufacturer datasheet. Figures as published by the manufacturer.
