White rectangular LED driver with aluminum heatsink fins, black power cable with exposed colored wires, mounted on white back

24V Dimmable LED Driver 200W 3in1 IP67 | Glacial GP-CVM200P-24VA

£89.20
Skip to product information
White rectangular LED driver with aluminum heatsink fins, black power cable with exposed colored wires, mounted on white back

24V Dimmable LED Driver 200W 3in1 IP67 | Glacial GP-CVM200P-24VA

Vendor
Glacial
SKU
999018
Availability
In stock
Weight
1.024 kg

£89.20inc VAT £74.33exc VAT

Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs

Secure checkout
Payment methods
  • American Express
  • Apple Pay
  • Bancontact
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Product Description

The Glacial GP-CVM200P-24VA is a constant voltage LED driver with a 24V DC output, built for LED strip lights and moving signs. One unit gives you three dimming methods: 0-10V, PWM or resistance. Its aluminium case is potted with heat-conducting silicone and sealed to IP67. That makes it a good fit for dusty, oily, humid or high-vibration locations where an open-frame supply would struggle.

24V dimmable LED driver features

  • Output: 24V DC, 0~8.3A, 199.2W
  • Dimming: 3in1, with resistance, 0-10V and PWM control
  • Input: universal AC, 90 ~ 305VAC range, rated 100 ~ 277VAC
  • Efficiency: 93% total at full load, with active power factor correction of 0.98
  • Standby draw: less than 0.5W with no load connected
  • Enclosure: IP67 insulated metal case, 230 x 80.3 x 33.5 mm, 840g

Cooling and operating conditions

There is no fan. The driver cools by free air convection, so there are no moving parts to wear out or clog with dust. It is rated to work from -30°C to +50°C.

Where to use it

Use it to power dimmable 24V LED strip lighting or moving signs. The sealed, silicone-potted housing suits installations in dusty, damp or high-vibration places, where moisture and grime would otherwise reach the electronics.

Choosing a dimming method

Because the driver accepts 0-10V, PWM and resistance dimming, you can match it to the control system already on site rather than sourcing a different driver for each one. Check which signal your dimmer or controller sends before wiring.

Technical Specifications 19 rows Show
BrandGlacial
ModelGP-CVM200P-24VA
TypeConstant voltage LED driver / power supply
Output voltage24V
Rated power200Watt
Dimming3in1 Dimmable: Resistance Dimming, 0-10V, PWM
EfficiencyTotal efficiency at full load 93%
Power factorActive power factor correction 0.98
No-load consumptionless than 0.5W
IP ratingIP67
HousingIP67 Metal Enclosure, aluminium, potted with silicone
CoolingFree air convection
Operating temperature-30°C and +50°C
Rated current0~8.3A
Rated input voltage100 ~ 277VAC
Input voltage range90 ~ 305VAC
Dimensions (L x W x H)230 x 80.3 x 33.5 mm
Weight840g/pcs
Suitable forLED strip and moving sign applications

Manufacturer datasheet. Figures as published by the manufacturer.
