24V LED Driver 36W 1.5A Constant Voltage Class II | Glacial
- Vendor
- Glacial
- SKU
- 999009
- Availability
- Sold out
- Weight
- 0.15 kg
£22.04inc VAT £18.37exc VAT
Sorry, this one is sold out
Tell us you want it and we will find out when it is back, or point you at the closest thing we have in stock.
Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
This Glacial 24V LED driver is a compact constant voltage power supply for LED strip lights, cabinet and display lighting and low voltage LED bulbs. It delivers 24V DC at up to 1.5A, giving a total load of 36W. Wiring goes in through screw terminals on both the input and output.
24V LED driver at a glance
- Output: 24V DC, 0-1.5A, 36W
- Mains input: universal AC input, 90-264VAC
- Efficiency: 85% at 230VAC full load
- Standby draw: no-load consumption <0.5W at 230VAC
- Housing: Class II, fully isolated plastic case
- Protection: over current, short circuit, over temperature and over voltage
Sizing your LED strip
Start with the watts per metre figure on your strip. The combined load must stay at or below 36W. As an example, this driver can run up to 5 metres of 7.2W per metre strip. Simple maths, but worth doing before you cut anything.
Where it fits
It suits 24V LED strip runs in kitchens, under cabinets, on shelving and inside showcases, along with retail display lighting. The small plastic case needs no earth connection, which keeps the wiring straightforward in tight spaces behind units or inside display furniture.
Installation notes
- Use only with 24V LED products and do not exceed 36W
- Allow ventilation and do not cover with insulation
- Installation should be carried out by a qualified person to current wiring regulations
Short circuit protection works in hiccup mode, and the driver recovers automatically once the fault is removed. Over current is handled by constant current limiting, also with automatic recovery.
Technical Specifications 26 rows Show
| Brand | Glacial |
| Output voltage | 24V DC |
| Rated output current | 0-1.5A |
| Rated output power | 36W |
| Voltage tolerance | ±5% |
| Ripple and noise | 240mVp-p max. |
| Efficiency | 85% minimum at 230VAC full load |
| Input voltage range | 90-264VAC |
| Rated input voltage | 100-240VAC |
| Frequency range | 47-63Hz |
| AC current | 1A at 115VAC / 0.5A at 230VAC |
| Inrush current | <30A at 115VAC / <60A at 230VAC |
| No load consumption | <0.5W at 230VAC |
| Protection | OCP, SCP, OTP and OVP |
| Over current protection | 110%-150% constant current limiting with automatic recovery |
| Short circuit protection | Hiccup mode with automatic recovery after fault is removed |
| Operating temperature | -20°C to 40°C |
| Operating humidity | 20% to 90% RH non-condensing |
| Storage temperature | -20°C to +80°C |
| Output type | Constant voltage |
| Class | Class II power design without earth connection |
| Case | Fully isolated plastic case |
| Connection | Input and output 2P screw terminal blocks |
| Terminal wire range | 0.75-1.5mm² input and output |
| EMC standards | EN55015, EN61000-4-2/3/4/5/6/11, EN61547, EN61000-3-2 Class C |
| Safety standards | EN61347-1, EN61347-2-13 |
Manufacturer datasheet. Figures as published by the manufacturer.
