Conversol A8 Off-Grid Inverter - 3kW, 24V, MPPT Charger, Bluetooth. Fast Charging

Ref: 90914116

£570.00

Price inc VAT

Bulk Savings £££
# Items	Our Price	Savings
6 Items	£552.90	Save 3%
12 Items	£535.80	Save 6%
24 Items	£524.40	Save 8%

Description

Specification

Downloads

Description

Conversol 3kW Off Grid Inverter

This 24V battery-based inverter is designed with zero transfer time perfect for critical loads such as servers and ATM. It is equipped with a powerful 140A super charger and 80A MPPT solar charger (60A AC utility charger). The LCD is removable to allow remote monitoring from a nearby room (up to 15-20 meters). The inverter is also ready for paralleling with identical units

Features

Zero transfer time
Detachable screen with multiple functions
Built in bluetooth for mobile monitoring
Supports USB On-The-Go function
Reserved communication port for BMS, RS485, CAN-Bus, RS232)
Parallel operation up to 9 inverters.

Specification

Conversol 3KVA super S3 145VDC

MODEL	Conversol 3K-24 Super S3
Rated Power	3000VA/3000W
INPUT
Voltage	120 VAC or 230 VAC
Selectable Voltage Range	95-140 VAC or 170-280 VAC (For Personal Computers) 65-140 VAC or 90-280 VAC (For Home Appliances)
Frequency Range	50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)	110/120 VAC ± 5% (User selectable) or 230VAC ± 5%
Surge Power	6000VA
Efficiency (Peak)	90% - 93%
Transfer Time	10 ms (For Personal Computers) 20 ms (For Home Appliances)
Waveform	Pure sine wave
BATTERY & AC CHARGER
Battery Voltage	24 VDC
Floating Charge Voltage	27VDC
Overcharge Protection	34VDC
Maximum Charge Current	80A +60A from AC Generator
SOLAR CHARGER
Maximum PV Array Power	1500 W
MPPT Range @ Operating Voltage	30 ~ 115 VDC
Maximum PV Array Open Circuit Voltage	145VDC
Maximum Charging Current	60A
Maximum Efficiency	98%
Standby Power Consumption	2 W
PHYSICAL
Dimension, D X W X H (mm)	140 x 300 x 512
Net Weight (kgs)	11.5
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	0℃ to 55℃
Storage Temperature	-15℃ to 60℃
