300W LED Flood Light Modular IP66 IK10 51,000lm | Athled
- Vendor
- Ledison
- SKU
- 103172
- Availability
- In stock
- Weight
- 5.0 kg
£364.34inc VAT £303.62exc VAT
Delivery from £7.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
The Athled is a modular 300W LED flood light for sports grounds, stadiums and large outdoor areas. This listing covers the 300W module. Fit one, two or three modules together to build a 300W, 600W or 900W unit. Each module is rated at 51,000lm ±5% with an efficacy of 170lm/W ±5%.
300W LED flood light: key features
- Light output: 51,000lm ±5% per 300W module
- Efficacy: 170lm/W ±5%
- Protection: IP66 and IK10, with a 20kV lightning arrester
- Beam options: 30 degree, 60 degree, 90 degree and asymmetric
- Aiming: each module rotates 360 degrees, and the lens is replaceable
- Service life: over 50,000 hours, with a 5-year warranty
Building your fitting
Power scales with the number of modules.
- 1 module: 300W
- 2 modules: 600W
- 3 modules: 900W
Before ordering, confirm the module count, beam angle, colour temperature and mounting arrangement you need. Colour temperature is offered at 3000K, 4000K or 6000K. If your site calls for less output, a lower power version built on 240W modules is sold as a separate listing.
Mounting and installation
The fitting can go on a ceiling, wall, pole or the ground. Every module is supplied with the bracket arrangement needed to make a complete unit. Start-up is instant. There is no warm-up time, so the lights reach full output as soon as they are switched on.
Where it is used
Football pitches and tennis courts are the obvious fit, along with other sports grounds and stadiums. Commercial users run the same fitting over warehouses, factories and yards, and it also suits ports, airports and power stations where a wide area needs lighting from a single mounting point.
Technical Specifications 26 rows Show
| Product type | Modular LED Flood Light |
| Module power | 300W |
| Lamp efficiency | 170lm/W ±5% |
| Luminous flux | 51,000lm ±5% |
| CRI | Ra >70 |
| Colour temperature | Natural white: 4000K, Cool white: 6000K |
| Rated voltage | AC 100V to 240V / 277V, 50/60Hz |
| Power factor | >0.95 |
| Beam angles | 30 degree, 60 degree, 90 degree and asymmetric |
| IP rating | IP66 |
| Impact protection | IK10 |
| Lifetime | over 50,000 hours |
| Surge protection | 20kV lightning arrester |
| Rotation | 360 degree rotatable module |
| Lens | Replaceable lens |
| Cooling | aluminium cooling fins |
| Installation | Ceiling, wall, ground or pole installation |
| Operating temperature | -40°C to +60°C |
| Module size | 344 x 184 x 238mm |
| Net weight | 6.0kg ±5% |
| Single box size | 390 x 295 x 235mm |
| Single box gross weight | 6.6kg ±5% |
| Carton size | 605 x 410 x 505mm |
| Carton gross weight | 27.4kg ±5% |
| Box quantity per carton | 4 pieces |
| Warranty | 5 year warranty offered as standard |
Manufacturer datasheet. Figures as published by the manufacturer.
