Elios 15kW Three-Phase Grid Tie Solar Inverter G98/G99 | Fanless
£1,537.99
Skip to product information
Elios 15kW Three-Phase Grid Tie Solar Inverter G98/G99 | Fanless
- Vendor
- Elios
- SKU
- PH50TM-15000
- Availability
- In stock
- Weight
- 25.0 kg
£1,537.99inc VAT £1,281.66exc VAT
Secure checkout
Talk to our sales team
Product Description
The Elios 15kW is a three-phase grid tied solar inverter with three independent MPPT controllers, Wi-Fi monitoring and fanless cooling. It is G98/G99 compliant for UK grid connection and suited to commercial and industrial solar PV installations. IP65 rated, with a maximum PV input of 18kW.
Key features of this grid tied solar inverter
- Output, 15kW three-phase on-grid output at 320 to 478VAC
- MPPT design, three independent MPPT controllers, 200V to 1000V DC range per MPPT
- String capacity, up to 20 panels in series per PV string
- Max PV input, 18000W
- Peak efficiency, 98.3% at full load
- Cooling, fanless natural convection through a large aluminium heatsink
- Protection rating, IP65 for outdoor installation
Product overview
The inverter converts solar DC power into three-phase 320 to 478VAC output for self-consumption or export. Three independent MPPT controllers let it manage three separate string inputs, useful on commercial roofs with multiple orientations or partial shading across different sections.
Fanless cooling removes moving parts entirely. Natural convection through the aluminium heatsink keeps operating temperatures in check without noise or maintenance, which suits noise-sensitive commercial sites.
Export limitation via CT clamp adjusts output in real time to match consumption, giving zero-export or a fixed export level as required by the DNO. Monitoring runs through the Wi-Fi app or a Solar Assistant Orange Pi controller for more detailed local and remote monitoring.
Applications
- Commercial and industrial three-phase grid-connected solar PV systems
- Multi-orientation rooftop arrays benefiting from three independent MPPTs
- Installations requiring export limitation, zero-export mode or net metering
- Noise-sensitive sites where fanless operation is needed
Installation and safety notes
Fitting must be carried out by a qualified electrician or MCS-accredited solar installer. Three-phase grid-connected inverters in the UK need a G99 application and DNO approval before connection. DC isolators, AC protection, surge protection and earthing must comply with BS 7671. CT sensors must be fitted by a qualified electrician; this is not a DIY installation.
Technical Specifications 27 rows Show
| Model | PH50- 15000TM | |
|---|---|---|
| AC output | Rated output power | 15000W |
| Max apparent power | 16500VA | |
| Max output current | 23.8A | |
| Nominal voltage | 230V \ 400V | |
| Voltage range | 184Vac-300Vac | |
| Grid frequency range | 50±5Hz | |
| 60±5Hz | ||
| Power factor at rated power | 1 | |
| Adjustable displacement power factor | 0.8leading. 0.8lagging | |
| THDi at full load | < 3% | |
| Grid connection type | 3W+N+PE | |
| Input data | Max DC power | 18000W |
| Max DC voltage | 1000V | |
| DC operating voltage range | 160-1000V | |
| Start voltage | 160V | |
| Max MPPT input current | 3x11A | |
| Number of MPPT trackers | 3 | |
| MPPT voltage range | 200-1000V | |
| Max short-circuit current per MPPT | 13.75A | |
| Number of DC inputs | 6 | |
| Efficiency | Max efficiency | 98.3% |
| Euro efficiency | 97.5% | |
| MPPT efficiency | >99.5% | |
| IP rating | IP65 | |
| Operating temperature | -25 to +60 deg C | |
| Weight | 24.5kg | |
| Dimensions (W x H x D mm) | 500 x 428 x 200 | |
Manufacturer datasheet. Figures as published by the manufacturer.
