Pylontech Force H3X hybrid solar inverter, white unit with black control panel displaying 100% charge status, manual switches

Pylontech Force H3X 6kW Hybrid Solar Inverter MPPT

£1,363.95
Skip to product information
Pylontech Force H3X hybrid solar inverter, white unit with black control panel displaying 100% charge status, manual switches
Pylontech Force H3X 6kW Hybrid Solar Inverter MPPT

Pylontech Force H3X 6kW Hybrid Solar Inverter MPPT

Vendor
Pylontech
SKU
003029
Availability
In stock
Weight
23.0 kg

£1,363.95inc VAT £1,136.63exc VAT

Delivery from £10.00 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs

Secure checkout
  • American Express
  • Apple Pay
  • Bancontact
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Talk to our sales team

Product Description

The Pylontech Force H3X FH3X6K-HY-1P is a single phase hybrid solar inverter and battery storage system rated at 6kW, built for solar self-consumption, grid import and export, smart tariff switching and backup power. This hybrid solar inverter pairs directly with Pylontech FH10050 high voltage LiFePO4 battery modules stacked vertically beneath the unit.

Pylontech Force H3X hybrid inverter overview

The inverter, BMS and energy management electronics are combined into one enclosure. Pylontech promotes a fast, simplified installation process of around 15 minutes on a properly prepared site, carried out by a qualified installer. The battery connection is wire-free, using an internal bus bar rather than separate power or communication cables between inverter and battery modules.

Key features

  • Nominal power, 6kW single phase output
  • Battery compatibility, Pylontech FH10050 high voltage LiFePO4 modules, stacked vertically
  • Grid interaction, CT clamp based monitoring of import and export, without a separate Eastron meter for standard operation
  • Backup power port, supplies selected essential loads during a mains outage
  • Smart tariff support, Intelligent Dynamic mode adjusts charging and discharging around tariff periods, including time-of-use pricing
  • Design, integrated inverter, BMS and energy management with fewer external components

Applications

Suited to home solar battery storage, solar self-consumption, smart import and export tariffs, backup power for essential circuits, and small offices, warehouses or commercial buildings using high voltage battery storage. The Force H3X platform can expand across residential and small commercial systems, subject to system design and manufacturer limits.

Installation

This is professional installation equipment. Grid connection, backup wiring, CT connection, DNO notification and electrical protection must all be completed by a qualified, competent installer in line with local regulations and the manufacturer's installation manual.

Technical Specifications 79 rows Show

Pylontech Force H3X FH3X6K-HY-1P Specification Table

Single phase hybrid energy storage system with 6kW nominal power, designed for use with FH10050 battery modules.

Technical Specification

Specification FH3X6K-HY-1P
Main System Data
Battery ModuleFH10050
Number of Battery Modules1 / 2 / 3 / 4
System Nominal Capacity5.12 / 10.24 / 15.36 / 20.48kWh
System Nominal Power6kW
DC Parameter, PV Side
Maximum Power9.6kW
Maximum Input Voltage600Vdc
Start Up Voltage80Vdc
MPPT Voltage Range80 to 550Vdc
MPPT Full Load Voltage Range190 to 520Vdc
Number of MPPT2
Number of PV Strings Per MPPT1
Maximum Current16A
Short Circuit Current Per MPPT25A
Surge ProtectionType II
DC Parameter, Battery Side
Maximum Continuous Charge / Discharge Current40A
Maximum Charging Power with One Battery2.5kW
Maximum Discharging Power with One Battery2.5kW
Maximum Charging Power with More Than One Battery8kW
Maximum Discharging Power with More Than One Battery6kW
AC Parameter, Grid Side
Nominal Grid Voltage1/N/PE a.c. 230V
Nominal Grid Frequency50 / 60Hz
Maximum Nominal Continuous Current to Grid26.1A
Nominal Active Power to Grid6000W
Maximum Nominal Apparent Power to Grid6000VA
Maximum Nominal Continuous Current from Grid39.1A
Nominal Active Power from Grid9000W
Maximum Nominal Apparent Power from Grid9000VA
Power Factor Range-0.8 to +0.8
THDi<3%
AC Parameter, Back-up Side
Nominal Voltage1/N/PE a.c. 230V
Nominal Output Frequency50 / 60Hz
Maximum Nominal Continuous Current26.1A
Maximum Nominal Apparent Power6000VA
Peak Off-Grid Power, 60s Estimate6200VA
Power Factor Range-0.8 to +0.8
On / Off-Grid Switching Time<=10ms
THDv<3%
Efficiency
Maximum Efficiency98%
European Efficiency97.5%
Protection
Anti-Islanding ProtectionYes
AFCI2.0 @ IEC63027
Insulation Resistor DetectionYes
Residual Current Monitoring UnitYes
Output Over Current ProtectionYes
Output Short ProtectionYes
Output Overvoltage ProtectionYes
DC SwitchYes
DC Reverse Polarity ProtectionYes
DC / AC Surge ProtectionType II
PV Overvoltage ProtectionYes
General Data
Dimensions, W / H / D540 x 665 / 835 / 1005 / 1175 x 350mm
Weight77 / 116 / 155 / 194kg
TopologyTransformerless
Operating Temperature Range-10 to 55°C
System Working Humidity Range0 to 100%
System Working Altitude<4000m
Common Noise Level, 1 metre<29dB
Maximum Parallel6
Protective ClassI
Overvoltage CategoryDC II / AC III
Ingress ProtectionIP55
System Salt Spray LevelC5-M
CoolingNatural Cooling
Standby Consumption, Night<15W
Communication PortalWIFI / WLAN / Bluetooth
DisplayLED
EPOInstalled
Standard Compliance
Battery and System StandardsUN38.3 / IEC61000-6 / VDE-AR-E-2510-50 2017-05 / IEC62619:2022 / IEC60730-1 / ISO13849 / IEC62477-1:2022
Electrical Safety StandardsEN 62477-1:2012+A12:2021 / IEC62109-1:2010 / IEC62109-2:2011
Grid ComplianceVDE-AR-N-4105:2018 / DIN VDE V 0124-100:2020 / EN50549-10 / EN50549-1 / PPDS Annex:2022+EN50549-10 / C10/11+EN50549-10 / EIFS+EN50549-10 / CEI0-21 / RD1699 RD661 RD413 / UNE 217002:2020 / NTS Version 2.1:2021 / UNE 217001:2021 / AS 4777.2 / AS60947.3 / G98 / G99 / TOR

Notes: When the ambient temperature exceeds 45°C, the PCS will reduce the power. When the altitude exceeds 2000m, the PCS will degrade the power.

Manufacturer datasheet. Figures as published by the manufacturer.
