Victron EasySolar-II 24/3000/70-32 MPPT 250/70 GX | PMP242307010

The Victron EasySolar-II 24/3000/70-32 MPPT 250/70 GX is an all-in-one inverter charger for 24V off-grid and self-consumption systems. It combines a MultiPlus inverter charger, an MPPT solar charge controller and a GX monitoring device in one wall-mounted enclosure, built for installers putting together residential or light commercial off-grid and backup power setups.

Key features of the Victron EasySolar-II 24/3000/70-32 MPPT 250/70 GX

• Inverter charger, 3000VA inverter with a 70A battery charger, rated for 24V battery banks.
• Solar charging, MPPT 250/70 controller handles up to 250V open-circuit PV voltage and 70A charge current.
• Monitoring, integrated GX device runs Venus OS, giving VRM portal access and DVCC support.
• AC input, 32A current limit for shore power or generator connection.
• PowerAssist, supplements a limited AC input with inverter power to prevent overload.
• Connectivity, VE.Bus, VE.Direct and VE.Can ports for integration with the wider Victron ecosystem.

Product overview

Three core components share one enclosure here: the MultiPlus inverter charger, the MPPT solar controller and the GX controller. On a 24V system the 3000VA continuous output covers most residential loads, and the 70A MPPT manages PV arrays up to 250V Voc without extra wiring between components.

The 70A charger runs an adaptive four-stage algorithm across lead-acid, AGM, gel and lithium chemistries. Because the MPPT, inverter and GX share a housing, commissioning needs no separate VE.Direct or VE.Bus runs between them, though the unit still connects out to other Victron devices over those same protocols.

Applications

• Off-grid residential systems with solar PV and battery storage.
• Backup power installations using a generator or a restricted grid connection as the AC source.
• Marine and vehicle setups needing a 24V all-in-one inverter charger with solar.
• Self-consumption and home storage systems on a 24V battery bank.
• Remote sites where one compact unit is preferred over separate components.

Installation notes

Fit this by a qualified electrician or accredited installer. It connects to 24V battery banks and accepts AC input from shore power or a generator. For any grid-connected UK installation, check G98 or G99 compliance. Battery-side connections at this current rating carry significant fault energy, so correct fusing and cable sizing matter. Commissioning is done through the VRM portal.

What's in the box

• EasySolar-II 24/3000/70-32 MPPT 250/70 GX unit
