600W Grid-Tied Solar Microinverter IP67 | Voltacon VMI600
- Vendor
- Voltacon
- SKU
- 002641
- Availability
- Sold out
- Weight
- 3.0 kg
£133.34inc VAT £111.12exc VAT
Sorry, this one is sold out
Tell us you want it and we will find out when it is back, or point you at the closest thing we have in stock.
Delivery from £7.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
The Voltacon VMI600 is a 600W single phase grid-tied micro inverter with integrated Wi-Fi monitoring, built for single panel installations. It performs individual maximum power point tracking at module level, which helps recover lost yield when panels are partially shaded or face different directions. It is G98 compliant and ENA registered, making it suitable for UK residential and commercial grid-connected solar systems.
Micro inverter features
- Output, 600W rated, 620VA peak
- MPPT, single MPPT per unit, voltage range 24-50V, operating range 16-60V
- Input current, max 18A, max short circuit current 20A
- Panel compatibility, 400-670W panels (60-75 full cells or 120-150 half cells)
- Efficiency, 96.5% peak, 96% European
- Power quality, power factor greater than 0.99, THD less than 3%
- Enclosure, IP67 weatherproof
- Monitoring, integrated Wi-Fi, no separate hub required
Product overview
A string inverter tracks an entire array as one unit, so shading or soiling on a single panel drags down the whole string's output. The VMI600 tracks each panel on its own MPPT, so one weak panel does not pull down the rest of the array. GaN MOSFET technology is used with no electrolytic capacitors or cooling fans, and a high-frequency transformer provides electrical isolation between the PV input and the AC output. Up to 8 units can be connected per string.
Applications
Suited to residential rooftops with partial shading or mixed panel orientations, building-integrated PV on walls or irregular surfaces, and commercial installations where module-level monitoring is wanted.
Installation and safety
Installation must be carried out by a qualified electrician or MCS-accredited solar installer. G98 notification to the DNO is required before connection. The VMI600 needs a live grid connection to operate and will not run off-grid or in parallel with off-grid inverters.
Technical Specifications 16 rows Show
| Parameter | Value |
| Model | VMI600 |
| Rated Output Power | 600 W |
| Max Output Power | 620 VA |
| MPPT Voltage Range | 24-50 V |
| Operating Voltage Range | 16-60 V |
| Max Input Current | 18 A |
| Max Short Circuit Current | 20 A |
| Peak Efficiency | 96.5% |
| European Efficiency | 96% |
| Power Factor | >0.99 |
| THD | <3% |
| Ingress Protection | IP67 |
| Warranty | 10 years standard; 25 years optional |
| Grid Compliance | G98 (UK), EN 50549-1 |
| ENA Registration | ZHEJI/15702/V1/A1 |
Manufacturer datasheet. Figures as published by the manufacturer.
