3 Gang 2 Way LED Dimmer Switch 3 x 15-180W Twin Plate | Varilight V-Com KQDP183W
- Vendor
- Varilight
- SKU
- KQDP183W
- Availability
- In stock
- Weight
- 0.15 kg
£92.35inc VAT £76.96exc VAT
Delivery from £4.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
This Varilight V-Com KQDP183W puts three LED dimmers on a white twin plate, each one wired for 2 way switching. It belongs to the V-Com Commercial series and is intended for larger LED loads. Every gang dims 15-180W without flicker, and there is no maximum number of lamps. Push the knob to switch on or off. Turn it to dim.
Why choose this 3 gang LED dimmer switch
- Load per gang: 15-180W LEDs, no maximum number of lamps
- Dimming method: V-Com intelligent leading edge (triac)
- Control: push-on/off rotary knob
- Soft start: brings the brightness up gently
- Minimum brightness: adjustable
- Thermal protection: cuts the power if the dimmer overheats
Where it fits
The V-Com range suits rooms with heavier LED loads on several circuits. Typical uses include LED ceiling panels, LED T8 and T5 tubes, and downlights, spotlights and bulbs. It is rated for indoor use only.
Finish and fitting
The plate is white plastic with matching white knobs. Overall dimensions are 85x145x47mm, with a 15mm deep faceplate and a recommended back box depth of 25mm. It runs on 230V 50Hz and meets BS EN 60669-2-1.
Choosing between Varilight ranges
Smaller loads may be better served elsewhere. Where a circuit carries up to 10 dimmable LEDs at a maximum of 100W per gang, Varilight's V-Pro push on/off or remote control dimmers are the better match. This V-Com model is the one to pick when each gang needs to handle up to 180W.
Technical Specifications 20 rows Show
| Brand | Varilight |
| Model | KQDP183W |
| Range | V-Com (Commercial) Series |
| Description | 3-Gang 2-Way Push-On/Off Rotary LED Dimmer 3 x 15-180W LEDs |
| Maximum load | LED: 180W per circuit, no maximum number of lamps |
| Plate | Twin Plate |
| Dimming type | Leading edge (triac) |
| Finish | White Plastic |
| Knob colour | White Knob |
| Dimensions | 85x145x47mm |
| Faceplate depth | 15mm |
| Recommended back box depth | 25mm |
| Barcode | 5021575582284 |
| Fixing centres | 120.6mm |
| Depth from mounting face | 14.6mm |
| Weight | 220g |
| Voltage | 230V 50Hz |
| Terminal (live) | 3.2mm, capacity 3 x 1.5mm² |
| Safety standard | BS EN 60669-2-1 |
| Use | Indoor Use Only |
Manufacturer datasheet. Figures as published by the manufacturer.
