T5 LED Tube 60cm 2ft 563mm 10W 1200lm Direct Mains | Ledison
- Vendor
- Ledison
- SKU
- 110973
- Availability
- In stock
- Weight
- 0.25 kg
£15.74inc VAT £13.12exc VAT
Delivery from £7.99 to mainland UK 3 to 5 working days. Or collect free from Coventry.All delivery costs
Product Description
This Ledison T5 LED tube is a 60cm (2ft) replacement for a fluorescent T5. It draws 10W and gives out 1200 lumens. There is no separate driver to fit, because the driver sits inside the tube, so it runs straight from the mains at 90-277VAC.
T5 LED tube features
- Output: 10 watts, 1200 lumens, 120 lumens per watt.
- Colour choice: warm white, natural white or cool white.
- Body: 22mm wide (T6 size), so the driver fits safely inside.
- End caps: rotate 180 degrees and lock into position.
- LED chips: SMD 2835, with no UV light.
- Lifetime and warranty: up to 50,000 hours, backed by a 5-year warranty.
Fitting and use
The 22mm body fits most standard T5 fittings. Because the end caps turn through 180 degrees and then lock, you can set the light facing the right way once the tube is in the fitting, which makes installation easier.
It is rated IP20. The tube has passed the 4000V high voltage insulation test.
Wiring
Power is needed at one end only. If your fitting feeds both ends, it will need a quick rewire before this tube goes in. The tube is not dimmable, so do not connect it to a dimmer circuit.
Choosing a colour
Warm white sits at 2700-3200K. Natural white covers 4000-5000K. For a crisper light, cool white runs at 5500-6500K. All three share the same 10W rating and 1200lm output, so the only difference is the tone of the light.
Technical Specifications 23 rows Show
| Fitting | T5 |
| Length (pin to pin) | 563mm |
| Diameter | 22mm |
| Body | 22mm T6 body |
| Wattage (rated) | 10 Watt |
| Voltage | 90-277VAC |
| Power factor | PF>0.95 |
| Driver | Built-in isolated driver |
| Power connection | single-ended |
| Lumen | 1200lm |
| Typical efficiency | 120lm/W |
| Colour temperature | Warm white: 3000K, Natural white: 4000K, Cool white: 6000K |
| Beam angle | 120deg. |
| LED chips | SMD 2835 |
| Dimmable | NO |
| IP rating | IP20 |
| Housing | aluminium housing |
| End caps | rotate by 180 degrees and can be locked into position |
| Weight | 165g |
| Average lifetime | 50,000 hours |
| Insulation test | 4000V high voltage insulation test |
| Certification | ROHS Compliant, CE, UL |
| Warranty | 5 years |
Manufacturer datasheet. Figures as published by the manufacturer.
Datasheets & documents
