Victron SmartSolar MPPT 150/70-Tr VE.Can

VICTRON SMARTSOLAR MPPT 150/70 TR-VE.CAN-BLUETOOTH

WITH AUTO DETECT BATTERY VOLTAGE 12V/24V/36V/48V

SOLAR CHARGE CONTROLLER

It charges 12V, 24V, 48V lead acid, and lithium batteries, controlled from the Victron application using bluetooth.

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximizes this energy harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.

PV TERMINAL OPTIONS:

• TR - one positive and one negative screw terminal.
• MC4 - 3 pairs of paralleled MC4 connectors.
• VE.Can mean daisy chain connection (multiple chargers operate in parallel mode) and monitoring via Can Bus.

MPPT: Ultra Fast Maximum Power Point Tracking By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

FEATURE HIGHLIGHTS COMMON TO ALL MODELS

• Ultra-fast Maximum Power Point Tracking (MPPT).
• Advanced Maximum Power Point Detection in case of partial shading conditions.
• Outstanding conversion efficiency.
• Natural convection cooling.
• Automatic battery voltage recognition.
• Flexible charge algorithm.
• Over-temperature protection and power derating when the temperature is high

REMOTE MONITORING AND CONTROL

Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or other devices via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by Bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.

OPTIONAL SMARTSOLAR CONTROL DISPLAY

By adding the SmartSolar Control Display you will be able to check the status of your Charger and battery-storage at a glance. Simply plug it into the face of your MPPT charger to provide you with real-time monitoring and set-up capabilities.

DOWNLOAD SECTION
