LED PL G24 - 10W

Ref: LDN-PLG24-10-105

£13.00

Price inc VAT

LED PL G24 10W bulb replacement 26W CFL

Amount
Bulk Savings £££
# Items Our Price Savings
6 Items £12.61 Save 3%
12 Items £12.22 Save 6%
24 Items £11.96 Save 8%
Specification
Downloads
Specification

Specification of the PL G24 LED Bulb - Philips Lumiled LED Chips

Fitting:

G24

Luminous flux:

950lm

Wattage (rated):

10 Watt

Color Rendering index:

>80

Voltage:

100-265Volt

Typical efficiency:

105lm/W

Line frequency:

50/60Hz

Fitting/Pins:

G24d-1,G24d-2,G24d-3
G24d-4,G24q-1,G24q-2
G24q-3,G24q-4, E27

Average lifetime:

50,000 hours

Net Weight per piece

120gr

Color Temperature:



Diameter

31.5mm

Warm white:

3000K

Height

176mm

Natural white:

4000K

Dimmable

NO

Cool white:

6000K

Warranty:

5 years

Operating Temp:

-40 OC to 50 OC

Certification:

ROHS Compliant, CE, UL

Wiring Instructions available to download here



The emergency kit is available here

Downloads

Certificates

ce emc certificate for PLG24 LED LAMP

EMC Certificate PLG24 LED Lamp

EMC Certificate 2004/108/EC

Download

LVD certificate for PLG24 LED LAMP

LVD Low Voltage Directive PLG24

Low Voltage Direct 2014/35/EU LED PLG24 Lamp

Download

Technical Manual

PLG24 EMERGENCY KIT

LED PLG24 data sheet and wiring instructions

LED PLG24 data sheet and wiring instructions

Download

Emergency Pack for PLG24 and PL-L2G11

Wiring instruction for emergency PLG24 & 2G11

Download
