Victron Orion 24/12-80 DC-DC Converter IP20 Binding Posts | ORI241280030

The Victron Orion 24/12-80 is a non-isolated DC-DC converter that steps a 24V DC input down to a regulated 12V DC output rated at 80A. It suits vehicles, marine installs and off-grid systems that need two separate DC voltage rails from one battery bank.

Key features of the Victron DC-DC converter

• Conversion, non-isolated 24V to 12V DC-DC conversion
• Output current, 80A continuous
• Protection rating, IP20, for enclosed and protected environments such as cabinets and panels
• Terminals, binding posts for straightforward cable connection without specialist tooling
• Weight, 0.95kg

Applications

Use it to power 12V accessories and loads from a 24V vehicle or marine electrical system, or to run a dual-voltage off-grid setup where both 24V and 12V rails are needed. It also fits commercial vehicle conversions with mixed 24V and 12V equipment, marine installations needing a stable 12V supply from a 24V bank, and industrial panel installs where IP20 protection is acceptable.

Installation notes

Because of its IP20 rating, this unit must go in a dry, protected enclosure and must not be exposed to moisture, condensation or dust. The non-isolated design means input and output share a common ground, which needs to be accounted for in the system wiring. Fit appropriate fusing on both input and output sides to match your cable ratings, and have the installation carried out by someone experienced with DC power systems.

What's in the box

• 1x Victron Orion 24/12-80 DC-DC converter with binding post terminals
