Victron Busbar 150A 2-Pole with 20 Screws and Cover | VBB115022020

The Victron Busbar 150A 2-Pole is a dual-rail DC distribution busbar rated at 150A, supplied with 20 screws and a protective cover. It gives battery banks, inverter installations and off-grid panels a common positive and negative connection point for multiple circuits.

Key features

• Current rating, 150A continuous.
• Poles, 2, housing both positive and negative rails in one unit.
• Screws included, 20, enough for several circuit connections.
• Cover, protective cover included to guard against accidental contact with live conductors.
• Weight, 0.212 kg.

Applications

A busbar lets each circuit connect directly to a shared rail instead of daisy-chaining terminals, which cuts voltage drop and makes fault-finding easier. This one suits DC distribution in off-grid solar systems, battery bank positive and negative rail connections in 12V, 24V or 48V setups, inverter DC input panels, and marine or motorhome electrical systems that need a central distribution point.

Installation notes

Fit this busbar by a qualified electrician familiar with DC distribution work. Keep the total connected load within the 150A rating, torque every connection to the correct screw specification, and fit the protective cover only once wiring is complete. A qualified or MCS-accredited installer is recommended for solar PV and battery storage work.

What's in the box

• 1x Busbar 150A 2-Pole
• 20x Screws
• 1x Protective cover
