Victron Orion 24/12-30 DC-DC Converter IP20 | ORI241230022

The Victron Orion 24/12-30 is a non-isolated DC-DC converter that steps a 24V DC input down to a regulated 12V DC output at up to 30A. It suits vehicle, marine and off-grid installations where a 24V system bus needs to feed 12V loads without a separate battery bank.

Key features of the Victron Orion 24/12-30 dc-dc converter

• Step-down conversion, 24V input to 12V output at up to 30A continuous current
• Protection rating, IP20, for enclosed dry locations only
• Weight, 0.7 kg
• Output power, 360W maximum
• Topology, non-isolated (buck), sharing a common ground between input and output

Product overview

The non-isolated topology suits the majority of vehicle and marine installations where the chassis or hull forms a shared negative. Where input and output circuits must be kept electrically separate, Victron's isolated Orion-Tr range is the appropriate choice instead. For standard 24V to 12V step-down duties on a shared-ground system, this non-isolated design is the more efficient option.

IP20 means protection against solid objects greater than 12mm, with no water or dust ingress protection. Install it in a dry, enclosed location such as a battery compartment, equipment locker or control panel enclosure. It is not suitable for direct exposure to moisture, spray or condensation.

Applications

• Supplying 12V accessories and control circuits from a 24V vehicle or truck electrical system
• Powering 12V loads aboard vessels with a 24V DC house bank
• Off-grid cabins with a 24V battery system requiring a 12V sub-circuit
• Telecom and industrial enclosures where a 24V bus feeds 12V control or communications equipment
• Motorhomes and coaches with a 24V chassis system needing a regulated 12V auxiliary supply

Installation notes

Fit this unit in a dry, enclosed location in line with its IP20 rating. Fuse the input wiring close to the source battery or busbar. The non-isolated design requires a shared negative between the 24V input and 12V output circuits, so it is not suitable where galvanic isolation is required. Size cabling for the 30A output current and allow adequate ventilation around the unit for heat dissipation.

What's in the box

• 1 x Victron Orion 24/12-30 non-isolated DC-DC converter
