Victron Phoenix Inverter 24/2000 230V Smart | PIN242201000

The Victron Inverter 24/2000 230V Smart converts 24V DC battery power into 230V AC at 2000VA continuous output, with a pure sine wave suitable for sensitive and motor-driven loads. Bluetooth is built in, so configuration and monitoring run through the VictronConnect app without a separate interface cable.

Key features

• Output, 2000VA continuous AC at 230V from a 24V DC input, pure sine wave.
• Bluetooth connectivity, built-in module for VictronConnect monitoring, configuration and firmware updates.
• PowerControl and PowerAssist, supplements a limited AC source such as a generator or shore power to prevent overload.
• Battery protection, configurable low voltage shutdown helps prevent deep discharge damage.
• GX ecosystem compatible, connects to a Victron GX device for system monitoring via the VRM portal.
• Weight, 13.2 kg, in an aluminium enclosure.

Product overview

Running from a 24V battery bank, the inverter delivers 2000VA of continuous 230V AC. The pure sine wave output works with virtually all AC loads, including motor-driven equipment and variable speed drives. A 24V bank is a common choice in medium-sized off-grid and marine systems, where it keeps cable runs and battery sizing more practical than a 12V setup.

The Smart designation refers to the built-in Bluetooth module. Through the free VictronConnect app on iOS or Android, an installer can set battery type, low voltage thresholds and PowerAssist parameters directly, with no extra display or cable needed. Connecting to a Victron GX device, such as a Cerbo GX, brings the inverter into a full monitored system through the VRM portal.

PowerAssist helps where a limited AC source, a small generator or a restricted shore connection, needs to cover loads that occasionally exceed its capacity. The inverter draws on the battery to make up the shortfall and recharges once demand drops, avoiding the need to oversize the generator or shore supply.

Applications

• Off-grid cabins and remote properties needing 230V AC from a 24V battery bank.
• Marine vessels with 24V DC systems supplying 230V AC appliances.
• Vehicle conversions such as motorhomes and expedition vehicles with 24V house batteries.
• Backup power for critical loads during mains outages, paired with a battery bank.
• Small commercial off-grid sites where a GX device provides full system monitoring.

Installation notes

Fit this inverter with a qualified electrician familiar with DC battery systems and 230V AC wiring. DC cable sizing between battery and inverter matters at 24V given the currents involved: use short, correctly rated cable runs with a fuse or breaker sited close to the battery. This is not a grid-tied inverter and does not require G98 or G99 notification. Where it forms part of a larger solar or battery storage system, a qualified installer should confirm the design meets BS 7671 wiring regulations.

What's in the box

• Victron Inverter 24/2000 230V Smart unit
