Victron Phoenix Inverter 24/1200 230V VE.Direct IEC | PIN242121110

The Victron Inverter 24/1200 230V VE.Direct IEC is a pure sine wave DC-to-AC inverter built for 24V battery systems, delivering 1200VA of continuous 230V AC output. It suits off-grid installations, marine and vehicle setups, and backup power systems where monitoring matters. The VE.Direct port connects it to the Victron GX device ecosystem and the VictronConnect app.

Key features of this victron power inverter

• Output, 1200VA continuous at 230V AC from a 24V DC input.
• Waveform, pure sine wave, suited to sensitive electronics and motor loads.
• Communication, VE.Direct port for Victron GX devices, MPPT chargers and the VictronConnect app via a VE.Direct to USB or Bluetooth dongle.
• Connector, IEC AC output socket for standardised wiring.
• Weight, 6.9 kg.
• Protection, low battery voltage shutdown, overload, over-temperature and short-circuit protection.

Product overview

This sits in Victron's VE.Direct inverter range, built for off-grid and backup jobs that need communication and monitoring without the complexity of a full inverter-charger. The 24V input suits mid-sized battery banks found in narrowboats, campervans, off-grid cabins and small commercial sites. At 1200VA it handles lighting circuits, small power tools, laptops and televisions.

The VE.Direct port lets the inverter report output power, battery voltage and alarm conditions to a Victron GX device such as the Cerbo GX, or to a smartphone through VictronConnect with a compatible interface accessory. The IEC output socket connects to standard IEC-format distribution without custom wiring. Pure sine wave output avoids the overheating and interference that modified sine wave units can cause in variable-speed motors or switched-mode power supplies.

Applications

• Off-grid cabins and remote buildings with 24V battery banks.
• Narrowboats and canal boats needing 230V AC from a 24V DC system.
• Campervans and motorhomes with 24V leisure batteries.
• Backup power for small commercial or agricultural premises.
• Telecoms and remote monitoring enclosures needing a monitored AC supply.
• Solar off-grid systems paired with Victron MPPT charge controllers and a GX device.

Installation notes

Connect to a 24V DC battery bank with correctly rated DC cabling and fusing, keeping DC runs as short as possible to limit voltage drop. Installation should be carried out by a qualified electrician familiar with DC power systems, and any work forming part of fixed building wiring must comply with BS 7671. The VE.Direct interface accessory needed for monitoring is sold separately.

What's in the box

• Victron Inverter 24/1200 230V VE.Direct IEC unit.
