Victron GlobalLink 530 Cellular VRM Monitoring | ASS030543030

The Victron GlobalLink 530 is a cellular monitoring device that links compatible Victron equipment to the VRM Online Portal over a 2G/3G/4G mobile network. No router or local internet connection is needed, which makes it a practical choice for off-grid, marine or mobile installations where fixed broadband simply isn't available.

Key features

• Cellular connection, built-in modem connects directly to the VRM Online Portal, no router or local network required.
• Compatibility, works with Victron products such as BMV battery monitors, SmartSolar MPPT charge controllers and Phoenix inverters via VE.Direct.
• VE.Direct ports, supports up to two VE.Direct connected devices simultaneously.
• Global SIM, built-in SIM card with data included, so there's no separate SIM to source or manage.
• Weight, 0.21 kg, compact enough for tight enclosures or mobile applications.
• Data logging, real-time and historical data available through the VRM portal or VRM app.

Product overview

The GlobalLink 530 suits installations where a GX device or local network isn't practical. It plugs directly into VE.Direct ports on supported Victron devices and sends data over cellular to the VRM Online Portal, covering battery banks, solar charge controllers or inverters in caravans, boats, remote cabins and other off-grid locations.

The included global SIM is pre-configured and managed by Victron. There's no contract to arrange and no APN to set up. Data is sent at regular intervals and stored on the VRM portal, so installers and owners can check system performance history, state of charge trends and fault events remotely.

Because it connects at the VE.Direct level rather than through a GX device, the GlobalLink 530 is a lower-cost monitoring option for smaller systems. It doesn't cover full GX functionality like DVCC, generator control or ESS, but for read-only remote monitoring it handles the common cases.

Applications

Remote monitoring of off-grid solar and battery systems without broadband, marine and narrowboat installations, caravans, motorhomes and van conversions, remote cabins, agricultural buildings and telecoms backup power, and installer fleet monitoring across multiple sites via one VRM account.

What's in the box

• 1 x Victron GlobalLink 530 unit with built-in global SIM

Installation notes

The GlobalLink 530 connects via VE.Direct cable to supported Victron devices. Check that the connected equipment supports VE.Direct data output before buying. It needs a power supply within its specified input voltage range, and while the unit itself involves no high-voltage wiring, the wider solar or battery system it monitors should be installed by a qualified electrician or accredited installer, meeting G98 or G99 requirements where applicable.
