Victron Blue Smart IP65 Charger 12/4(1) 230V CEE 7/16 | BPC120435034R

The Victron Blue Smart IP65 12/4 is a single-output battery charger rated at 12V 4A, built for lead-acid and lithium batteries in vehicles, boats, caravans and off-grid setups. The IP65 enclosure copes with damp or dusty conditions, and built-in Bluetooth links straight to the VictronConnect app for monitoring and configuration.

Key features of the Victron Blue Smart charger

• Enclosure rating, IP65, protected against dust ingress and low-pressure water jets.
• Bluetooth, connects directly to VictronConnect on iOS and Android, no extra hardware needed.
• Output, 12V 4A, single output.
• Mains input, 230V AC via CEE 7/16 (Europlug).
• Charging, multi-stage adaptive algorithm with bulk, absorption and float phases, plus an optional storage mode.
• DC connection, pre-fitted DC connector, no crimped ring terminals required.

Product overview

The fully sealed housing suits engine bays, outbuildings and marine environments where an unrated charger would struggle. At 4A the charger suits batteries in the 14Ah to 100Ah range: motorcycles, small leisure vehicles, caravans and backup systems. All charge parameters can be viewed and adjusted over Bluetooth via VictronConnect, so there's no separate interface cable to carry.

The unit ships with a CEE 7/16 Europlug, the two-pin plug standard across continental Europe. It does not fit a UK three-pin socket, so UK buyers will need a suitable adaptor. The DC output uses a pre-fitted connector rather than bare leads.

Applications

• Motorcycle and scooter battery charging and maintenance.
• Caravan and motorhome leisure battery top-up during storage.
• Small boat or RIB auxiliary battery charging in damp marine environments.
• Off-grid cabin or shed battery maintenance.
• Backup battery systems needing periodic float maintenance.

What's in the box

• Victron Blue Smart IP65 12/4 charger (1 output)
• CEE 7/16 (Europlug) mains cable
• DC output connector
• Retail packaging

Installation notes

Connect the DC output to the battery before the mains supply. The 230V AC input needs a CEE 7/16 to BS 1363 adaptor for UK sockets. Mount the charger somewhere ventilated and away from fuel sources on vehicles or marine craft. Basic charging needs no electrical qualification, but permanent wiring into a vehicle or vessel should go to a competent electrician or marine engineer.
