Victron Inverter 48/250 230V VE.Direct SCHUKO | PIN481251200

The Victron Inverter 48/250 is a compact 250VA pure sine wave inverter for 48V DC battery systems, converting stored energy to 230V AC output through a SCHUKO socket. It suits off-grid installations, marine and vehicle applications, and small standalone power systems where a lightweight, low-power inverter is needed.

Key features of the victron inverter 48/250

• Output, 250VA continuous at 230V AC from a 48V DC battery bank
• Waveform, pure sine wave, suited to sensitive electronics and motor loads
• Communication, VE.Direct port for monitoring with Victron GX devices and VictronConnect
• Socket, SCHUKO output for direct connection of standard European plugs
• Weight, 2.6 kg, compact for space-constrained installations
• Protections, over-temperature, overload and low battery voltage shutdown built in

Product overview

The 48/250 runs on a 48V nominal battery input, the preferred voltage for larger off-grid and backup systems because it brings lower cable losses and reduced current draw than 12V or 24V equivalents. At 250VA it is intended for small loads: lighting, low-power tools, charging equipment or consumer electronics rather than high-draw appliances.

The VE.Direct port lets the inverter talk to Victron's ecosystem, including the Color Control GX, Cerbo GX and the VictronConnect app via a VE.Direct to USB or Bluetooth dongle. That gives real-time monitoring of input voltage, output load and alarm status without extra hardware beyond the communication cable.

The SCHUKO socket makes deployment straightforward in European contexts and in the UK with an adaptor. The pure sine wave output works with switch-mode power supplies that can be sensitive to modified sine wave sources.

Applications

• Off-grid cabins and remote power systems with 48V battery banks
• Marine vessels needing a compact 230V AC supply from a 48V DC system
• Campervans and motorhomes with 48V lithium or AGM battery installations
• Small backup power supplies for low-draw critical loads
• Telecoms and monitoring enclosures needing a local 230V AC outlet

What's in the box

• Victron Inverter 48/250 230V VE.Direct SCHUKO unit

Installation notes

This inverter connects directly to a 48V DC battery bank. DC wiring must be sized correctly for the current draw and protected with a suitably rated fuse or circuit breaker close to the battery. Installation should be carried out by someone competent with DC electrical systems, and a qualified installer is recommended for integration into a wider solar or off-grid system. This unit is not grid-tied and does not require G98 or G99 notification. The SCHUKO output is not a standard UK BS1363 socket, so a suitable adaptor is needed for UK plug types.
