Victron Inverter 24/800 230V VE.Direct SCHUKO | PIN241801200

The Victron Inverter 24/800 converts 24V DC battery power into 230V AC pure sine wave output, rated at 800VA continuous. It suits off-grid installations, marine and vehicle setups, and backup power systems where a compact DC-to-AC inverter is needed. A SCHUKO output socket lets you plug in standard European appliances without adapters.

Key features of the Victron inverter

• Output, 800VA continuous at 230V AC from a 24V DC battery bank.
• Waveform, pure sine wave, suitable for sensitive electronics, motors and compressors.
• Monitoring, VE.Direct port for communication with Victron GX devices and the VictronConnect app.
• Socket, SCHUKO output for direct connection of standard European plugs.
• Weight, 5.8 kg.
• Protection, low battery voltage shutdown, over-temperature and overload protection.

Product overview

Running from a 24V nominal battery system, this inverter suits off-grid cabins, narrowboats, campervans and small backup power setups. At 800VA continuous it handles lighting, small power tools, laptops, televisions and similar appliances within its rating. Because the output is pure sine wave, it also runs inductive loads such as motors and compressors.

The VE.Direct port lets the inverter communicate with Victron's GX range, including the Cerbo GX, and can be monitored through VictronConnect via a VE.Direct to USB or Bluetooth dongle. This brings it into a wider Victron Energy monitoring setup without extra hardware beyond the communication cable.

Applications

• Off-grid cabins and remote buildings running from a 24V battery bank.
• Narrowboat and canal boat 230V AC supply from a 24V domestic battery system.
• Campervan and motorhome AC power for appliances and electronics.
• Small backup power systems for critical loads during grid outages.
• Telecoms and industrial enclosures needing a monitored 230V AC supply from DC battery.

What's in the box

• Victron Inverter 24/800 230V VE.Direct SCHUKO unit.

Installation notes

Fit this inverter with correctly fused and sized DC cabling to the 24V battery bank. It is not grid-tied, so G98 or G99 compliance does not apply, but fixed AC wiring on its output must meet BS 7671 wiring regulations. Marine installers should follow the relevant IEC or RYA guidance. VE.Direct communication cables are sold separately.
