Victron Phoenix Inverter 24/375 230V VE.Direct IEC | PIN241371100

The Victron Phoenix Inverter 24/375 converts 24V DC from a battery bank into a 375VA continuous 230V AC pure sine wave supply. It suits off-grid cabins, marine 24V systems and vehicle conversions where a compact inverter is needed for lighter loads such as chargers, LED lighting and small power tools.

Key features

• Output, 375VA continuous at 230V AC from a 24V DC input.
• Waveform, pure sine wave, suitable for sensitive electronics and motor loads.
• Monitoring, VE.Direct port for connection to a Victron GX device, MPPT display or the VictronConnect app via a VE.Direct to USB or Bluetooth dongle (sold separately).
• Connector, IEC AC output socket for direct appliance connection.
• Protection, low battery voltage shutdown, over-temperature and overload protection, factory set.
• Weight, 3.25 kg.

Product overview

Pure sine wave output means the Phoenix 24/375 replicates grid-quality power, so it runs inductive loads such as small motors and fans alongside electronics that would struggle on a modified sine wave. At 375VA it is sized for lighter circuits rather than heavy appliances. The VE.Direct interface lets it sit inside a wider Victron monitoring setup, and the IEC socket allows a straightforward plug-in connection in a van, boat or small cabin.

Installation notes

This unit runs on a 24V DC supply and needs correctly fused, appropriately sized DC wiring. It is not grid-connected, so G98 or G99 compliance does not apply. Installation should be carried out by a qualified electrician or experienced system integrator, with adequate ventilation around the unit to avoid thermal shutdown under sustained load.

Applications

• Off-grid cabins and remote buildings needing 230V AC from a 24V bank.
• Marine installations with a 24V house battery system.
• Campervan and motorhome conversions.
• Backup power for small office or telecoms equipment.
• Portable setups integrated into a Victron VE.Direct monitoring system.

What's in the box

• Victron Phoenix Inverter 24/375 230V VE.Direct IEC unit
