Victron Inverter 24/375 230V VE.Direct IEC | PIN241371110

The Victron Inverter 24/375 converts 24V DC to 230V AC pure sine wave power, giving a 375VA continuous output in a compact unit built for off-grid and mobile installations. A VE.Direct port lets it report into Victron's monitoring ecosystem, and the IEC output socket makes connecting standard appliances straightforward.

Key features

• Output, 375VA continuous, 230V AC pure sine wave from a 24V DC input.
• Communication, VE.Direct port for connection to Victron monitoring devices such as the Color Control GX and Venus GX.
• AC connector, IEC socket for standard European and UK appliances via an appropriate lead.
• Weight, 3.25 kg, suited to space-constrained vehicle, marine and off-grid installs.
• Protections, automatic shutdown on low battery voltage, overload and over-temperature, with automatic reset once the fault clears.
• Idle draw, low standby power consumption, relevant where autonomy depends on battery capacity.

Product overview

Sitting at the entry point of Victron's VE.Direct inverter range, the 24/375 suits 24V battery banks common in marine, vehicle and small off-grid systems. At 375VA it is intended for individual loads: lighting circuits, routers, CCTV, control panels or small appliances, rather than whole-property supply.

The VE.Direct interface feeds status data into a GX device and onward to VRM, useful for unattended or remote installations where checking inverter status in person is impractical.

Applications

• Off-grid cabins and shelters needing a single 230V AC output from a 24V bank.
• Marine and narrowboat installations already wired at 24V DC.
• Vehicle conversions requiring a compact 230V source.
• Telecoms and CCTV equipment on 24V battery backup.
• Small solar-plus-storage systems monitored through a GX device and VRM.

What's included

• Victron Inverter 24/375 230V VE.Direct IEC unit

Installation notes

Fit this inverter with correctly rated DC wiring and a fuse or breaker sized for 24V current, positioned close to the battery. The IEC output is not for connection to a building's fixed wiring without proper isolation and compliance with BS 7671; installation should be carried out by a qualified electrician or system integrator.
