Ledison Downlighter 25W

LED ROUND PANEL LIGHT 22W RECESSED DOWNLIGHT

Ref: GL-DL10

£34.90

Price inc VAT

Omikron Recessed LED Panel 4 inches, with Dimmable Options and Three Colour Temperatures.

Amount
Bulk Savings £££
# Items Our Price Savings
6 Items £33.85 Save 3%
12 Items £32.81 Save 6%
24 Items £32.11 Save 8%
Description
Specification
Downloads
Description

THE BRIGHTEST LED ROUND PANEL. 2500 LUMENS. 22WATT

22Watt producing 2500 lumen. That's our proposal for a bright environment. This is our most powerful Round Panel, manufactured at highest possible standards to please even the most demanding lighting needs.

CUT-OUT HOLE: 285MM. OUTER DIAMETER: 300MM
FIND OUT WHY OUR LED PANELS ARE THE RIGHT CHOICE.
VISIT OUR BLOG TO CONVINCE YOURSELF OF OUR QUALITY. CLICK HERE TO GO TO THE ARTICLE WE PREPARED FOR YOU.

CUSTOMIZATION FOR WELLNESS

Choose from the colour options we offer to express your creativity with a personal touch and pair your installation with dimming functionality for maximum customizability.

If you still doubt the standards of our 22W Round Panel, we have to remind you that all of our products come with 5 years warranty policy. This is how much we trust our products.

FASHINOABLE CHOICE FOR A WHOLE RANGE OF APPLICATIONS

Brighten up your office or make a stylish addition to your home. With our wide range of products, we are confident that we can provide a solution for any of your needs.

  PRODUCT FEATURES

  • Elegant structure, designed to dissipate heat
  • Slim and low profile design
  • LED Power Consumption: 22W
  • Low heat output
  • Passed IEC 60598-1(2008 )、IEC 60695-2-11 850°C glow wire test (optional )
  • Dimmable version also available
Specification

Technical Specifications 25w LED Panel lIGHTS

Type LDN-DL10DA-WW      LDN-DL10DA-NW    LDN-DL10DA-CW
Energy Used                                          25W
Rated Life                                    50,000 Hours
Input Voltage                                    100-240V AC
Power Factor (PF)                      0.95 @120V AC, 0.94@240V AC
CCT(color)           3000K         4000K         5700K
Luminous Flux          2125lm         2250lm        2500lm
Luminous Efficacy           85lm/W        90lm/W       100lm/W
CRI (Typ.)              80             80            80
Beam Angle                                        120°
Dimension                                  Ф 300 x 12mm
IP Rating                                       IP20
Operation Temperature                                -20°C ~ +40°C
Net. Weight                               1kg (with driver)
Package                                  10 PCS / Carton



Dimensions

 /live/pages/DL10-Dimensions.jpg



Downloads

Technical Manual

Emergency pack in galvanized enclosure

Remote emergency pack VOL-EL125

Remote emergency pack for LED panels, tubes and arrays

Download

LED Panel Light Omikron

Wiring Instructions & Dimensions Omikron LED Panel Recessed Light

Download

OMIKRON Slim Round LED Panel Lights

User's Manual DL04-DL06-DL08-DL10 Dimmable-Non Dimmable

Download
