Ledison LED Round Panel 18W

LED ROUND PANEL LIGHT 17W RECESSED DOWNLIGHT

Ref: GL-DL08

£31.90

Price inc VAT

Omikron Recessed LED Panel 4 inches, with Dimmable Options and Three Colour Temperatures.

Amount
Bulk Savings £££
# Items Our Price Savings
6 Items £30.94 Save 3%
12 Items £29.99 Save 6%
24 Items £29.35 Save 8%
Description
Specification
Downloads
Description

LED ROUND PANEL LIGHT 17W RECESSED DOWNLIGHT

Round panel recessed downlights are elegant and powerful, providing a consistent light to a home or office while also offering big savings on an electric bill. This 18W light is available in three colours: cool white, natural white, and warm white. Dimmable options are also available to increase the ability to customise lighting needs. These lights need a 225mm cut out and have a total outer diameter of 240mm.

These panels are guaranteed for 50,000 hours of continuous usage – that’s almost 20 years of lighting for your home, office, or other space. LEDs offer low heat output, and the design of this round panel further dissipates the heat that is generated. This panel is affordable, reliable, and elegant – the perfect choice for your needs.

FEATURES

  • Elegant structure, designed to dissipate heat
  • Slim and low profile design
  • LED Power Consumption: 18W
  • Low heat output
  • Passed IEC 60598-1(2008 )、IEC 60695-2-11 850°C glow wire test (optional)

DIMENSIONS

/live/pages/Dimmensions-DL08.jpg



Specification

Technical Specifications

Type GL-DL08DA-WW GL-DL08DA-NW GL-DL08DA-CW
Energy Used                                          18W
Rated Life                                    50,000 Hours
Input Voltage                                    100-240V AC
Power Factor (PF)                      0.95 @120V AC, 0.94@240V AC
CCT(color)           3000K         4000K         5700K
Luminous Flux         1530lm         1620lm       1800lm
Luminous Efficacy          85lm/W         90lm/W        100lm/W
CRI (Typ.)              80             80            80
Beam Angle                                        120°
Dimension                                   Ф 240 x 12mm
IP Rating                                       IP20
Operation Temperature                                -20°C ~ +40°C
Net. Weight                               720g (with driver)
Package                                  10 PCS / Carton






Dimensions

/live/pages/Dimmensions-DL08.jpg



EAN CODES:

EAN 0610877897186 Warm White
EAN 0610877897193 Natural White
EAN 0610877897209 Cool White



Downloads

Technical Manual

Emergency pack in galvanized enclosure

Remote emergency pack VOL-EL125

Remote emergency pack for LED panels, tubes and arrays

Download

OMIKRON Slim Round LED Panel Lights

User's Manual DL04-DL06-DL08-DL10 Dimmable-Non Dimmable

Download

LED Panel Light Omikron

Wiring Instructions & Dimensions Omikron LED Panel Recessed Light

Download
